Outdoor FTTH Single mode fiber optic drop cable with FRP Strength
Member(self-support FTTH)
Product Description
FTTH (Fiber to The Home) is a kind of transmission cable used to
connect directly to a home user or a business user. With no limits
to its bandwidth, wavelength and transmission technology and being
suitable for the application of various new services, FTTH cable is
the best solution for the connection between the internet backbone
to the user’s desktop.
Purchasing Risk
Many domestic small factories modified electric-wires equipment to
produce FTTH cable. They used unqualified fibers which is with very
cheap price 3USD/KM to imitate G657 bend-resistant fiber, waste
electric-wires and rubber slippers smashed as pvc raw material for
the LSZH outer sheath. Those inferior cables will cause many
problems such as short transmission distance, low bandwidth, intermittent signal and easy-to-crack of the cable
jacket in several months, etc.
The optical fiber unit is positioned in the centre. Two parallel
Fiber Reinforced Plastics (FRP) are placed at the two sides. A
steel wire as the additional strength member is also applied. Then
the cable is completed with a black or color LSZH sheath.
Characteristics
1 · Special low-bend-sensitivity fiber provides high bandwidth and
excellent communication transmission property;
2· Two parallel FRP strength members ensure good performance of
crush resistance to protect the fiber;
3· Single steel wire or massagers as the additional strength member
ensures good performance of tensile strength;
4· Simple structure, light weight and high practicability;
5· Novel flute design, easily strip and splice, simplify the
installation and maintenance;
6· Low smoke, zero halogen and flame retardant sheath.It protect
environment,can resist the ultraviolet rays,and prevent dehisce.
Application:
Adopted to outdoor level and vertical distribution.
Suitable for connect with communication equipment.
Long distance and local area network communication.
